| CPU Support |
Supports Intel® Core™ 14th, 13th, and 12th Gen Processors, Intel® Pentium® Gold, and Celeron® Processors (LGA 1700 Socket) |
| Chipset |
Intel® B760 Chipset |
| Memory (RAM) |
2x DIMM slots, Dual-Channel, Max capacity 128GB
• Supports up to DDR5 6400+(OC) MHz
• Supports Intel® XMP 3.0 OC
|
| Expansion Slots |
• 1x PCIe 4.0 x16 slot (from CPU)
• 1x PCIe 3.0 x1 slot (from Chipset)
|
| Display / Graphics |
• 1x HDMI™ 1.4 port (supports up to 4K @ 30Hz)
• 1x VGA port (supports up to 2048x1536 @ 50Hz)
(Requires processor with integrated graphics)
|
| Storage |
• 1x M.2 slot (M.2_1, PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices)
• 4x SATA 6Gb/s ports
• Supports RAID 0, RAID 1, RAID 5, and RAID 10 for SATA storage
|
| USB Ports |
Rear Panel: 2x USB 3.2 Gen 1 5Gbps Type-A, 4x USB 2.0
Front: 2x USB 3.2 Gen 1 5Gbps Type-A, 4x USB 2.0
|
| LAN (Network) |
Realtek® RTL8111H Gigabit LAN |
| Audio |
Realtek® ALC897 Codec
7.1-Channel High Definition Audio with Audio Boost
|
| Internal I/O Connectors |
• 1x 24-pin ATX main power connector
• 1x 8-pin CPU power connector
• 1x CPU fan, 2x system fan headers
• 1x RGB LED connector (JRGB)
• 1x Front panel audio & system headers
• 1x Serial (COM) port & 1x TPM pin header
|
| Special Features |
• Core Boost digital power design
• Memory Boost technology
• PCI-E Steel Armor slot protection
• 4x EZ Debug LEDs for easy troubleshooting
|
| Operating System |
Support for Windows® 11 64-bit, Windows® 10 64-bit |
| Form Factor |
Micro-ATX (mATX)
Dimensions: 200mm x 236.16mm
|
