| Graphics Architecture |
AMD RDNA 2 (Navi 23 XT) |
| Process Node |
TSMC 7nm |
| Stream Processors / Cores |
2048 (32 Compute Units) |
| Ray Tracing Accelerators |
32 Cores |
| Base Clock |
1968 MHz |
| Game Clock |
2359 MHz |
| Boost Clock |
Up to 2589 MHz |
| Memory Size & Type |
8 GB GDDR6 |
| Memory Bus Width |
128-bit |
| Memory Speed / Bandwidth |
16 Gbps / Up to 256 GB/s |
| Infinity Cache |
32 MB |
| Bus Interface |
PCI Express 4.0 x8 |
| Total Board Power (TDP) |
160W |
| Recommended PSU |
500W |
| Power Connectors |
1x 8-pin |
| Display Outputs |
3x DisplayPort 1.4a, 1x HDMI 2.1 |
| API Support |
DirectX 12 Ultimate, OpenGL 4.6 |
